10
LITTLE
WONDER
BLOWER
(BLOWER SHOWN WITH HONDA GC160 ENGINE.
OTHER ENGINES ARE SIMILAR.)
SWITCH (A)-SUBARU ONLY (not shown)
Move to the “OFF” position to stop the engine.
Move to the “ON” position before starting engine.
THROTTLE (B)
Controls engine speed and the amount of air
being blown.
91270-03-01 model has an engine mounted
throttle control.
CHOKE (C)
Move to the “CHOKE” position to apply the
choke. Move to the “RUN” position to remove
the choke.
FUEL SHUT OFF (D) SUBARU ONLY (not shown)
Move to the “OFF” position to shut off the fuel
whenever transporting the machine by trailer
or truck or during storage. Move to the “ON”
position before starting the engine.
. LOCKING KNOB (F)
Tighten the knob to lock the horizontal deflector
in the desired position. Loosen to allow the
deflector to be rotated with remote horizontal
deflector levelr.
VERTICAL DEFLECTOR (G)
Rotate the deflector to direct air discharge
forward or to the side.
CONTROLS
Honda Shown
