Page 96
For
a
model
with
a
touch
pad,
detach
the
touch
pad
connector
by
pulling
the
tab
with
your
fingers
in
the
direction
of
arrow
4 .
Then
remove
the
palm
rest
in
the
direction
of
arrow
5 .
For
other
models,
skip
step
4 .
4
5
When
installing:
On
a
model
with
a
touch
pad,
make
sure
that
connector
4
is
firmly
attached.
Note
for
LG-IBM
models
(Korea)
in
T40/T40p
series:
New
palm
rest
FRU
is
shipped
with
the
LG-IBM
logo
plate.
When
you
replace
the
palm
rest,
you
need
to
stick
the
LG-IBM
logo
plate
as
shown
in
this
figure.
15 mm
15 mm
Removing
and
replacing
a
FRU
90
T40/T40p,
T41/T41p,
T42/T42p
