A-2 INSTALLATION A-2
15-110 VDC (5 Amps Maximum)
Across the Arc Model
300 Amps 60% Duty Cycle
250 Amps 100% Duty Cycle
TEMPERATURE RANGE
OPERATION: - 40 o C to +50 o C (- 40 o F to +104 o F)
STORAGE: - 40 o C to +70 o C (- 40 o F to +185 o F)
RATED CURRENT
INPUT VOLTAGE
TECHNICAL SPECIFICATIONS – LN-15 (K1870-1), (K1870-2 CE)
HEIGHT WIDTH DEPTH WEIGHT
12.7 Inches 8.7 Inches 23 Inches 30lbs
(323 mm) (221mm) (584 mm) (14kg)
SPOOL SIZE CAPABILITY
8 (200mm) Dia. x 4 (100mm)
Wide Spools including
AWS 8 DIA. (10-15lbs)
JIS S-3 200mm max. (5 - 7 kg)
DIN 200 (5 kg)
ELECTRODE DIAMETERS and SPEED RANGE
PHYSICAL DIMENSIONS
Electrode Size Speed Range
0.023 - 0.052" 50 - 700 in/min
(0.6 - 1.3 mm) (1.3 - 17.8 m/min)
0.0345 - 5/64" 50 - 400 in/min
(0.9 - 2.3 mm) (1.3 - 10.1 m/min)
Solid Electrode
Steel
Flux Cored
Electrode
