EXTERNAL
EQ
UIPMENT
SETUP
23
Composite (RCA) Connection
Connect the A A U U D D II O O/V V II D D E E O O jacks between TV and
VCR. Match the jack colors (Video = yellow, Audio Left
= white, and Audio Right = red)
1. How to connect
2. How to use
■ Insert a video tape into the VCR and press PLAY on the
VCR. (Refer to the VCR owner’s manual.)
■ Select the A A V V 1 1 input source on the TV using the IIN N P P U U T T
button on the remote control.
■ If connected to A AV V IIN N2 2, select A A V V 2 2 input source on the TV.
1
2. How to use
■ Insert a video tape into the VCR and press PLAY on the
VCR. (Refer to the VCR owner’s manual.)
■ Select the A A V V 1 1 input source on the TV using the IIN N P P U U T T
button on the remote control.
G G If you have a mono VCR, connect the audio cable
from the VCR to the A
AU UD DIIO O LL((M MO ON NO O)) jack of
the TV.
NOTE !
ANTENNA IN M.P.I.
L R S-VIDEO VIDEO
VIDEO MONO ( ) AUDIO
R
A
V
IN 1
A
V
IN 1
VIDEO AUDIO
COMPONENT IN
S-VIDEO
( )
1
S-Video Connection
Connect the S-VIDEO output of the VCR to the
S
S --V V II D D E E O O input on the TV.
Connect the audio outputs of the VCR to the A A U U D D II O O
input jacks on the TV.
1. How to connect
2
1
( ) ( )
( )
L R S-VIDEO
AUDIO
HDMI/DVI IN SERVUCE ONLY
VIDEO MONO ( ) AUDIO
A
V
IN 1
A
V
IN 1
VIDEO AUDIO
COMPONENT IN
S-VIDEO
1 2
G G Do not connect to both Video
and S-Video at the same time. In
the event that you connect both
Video and the S-Video cables,
only the S-Video will work.
CAUTION
G G S-Video provides better quality than composite. Use
it when available.
NOTE !
