Specifi cations
Mains voltage
230VAC +10/-20%, 47...63Hz
Output/nominal voltage
typ. 27.6VDC
Output current
max. 2.2A
Output current siren outputs
output 1
max. 1A
output 2
max. 0.5A
(the sum of the currents of the signalling devices that are connected to the two outputs must not exceed 1A!)
Own current consumption at 24V
typ. 70mA (without optional componentries, line termination 5.6kΩ)
typ. 55mA (without optional componentries, line termination 47µF)
Line voltage
typ. 20V (line termination 5.6kΩ)
typ. 23V (line termination 47µF)
Line current without fi re detectors
typ. 3.7mA (line termination 5.6kΩ)
typ. 0mA (line termination 47µF)
Line termination
5.6kΩ or 47µF
Line resistance
max. 50Ω per core
Ambient temperature
-5°C to +50°C
Relative humidity
max. 95% (no condensation)
Dimensions W × H × D
330 Ч 330 Ч 90 (mm)
Colour
grey-white, RAL 9002
Weight without batteries
approx. 3kg
Approval
tested according to EN 54-2, EN54-4
VdS approval pending
Fire Detection Control Panel BC06-1
Order number
210205
Order name
Fire Detection Control Panel BC06-1/INT1
Fire Detection Control Panel BC06-2
Order number
210209
Order name
Fire Detection Control Panel BC06-2/INT1
