Appendix B: Configuring IPSec between a Windows 2000 or XP Computer and the Gateway
Introduction

ADSL Gateway with 4-Port Switch

Appendix B: Configuring IPSec between a Windows 2000

or XP Computer and the Gateway

Introduction

This document demonstrates how to establish a secure IPSec tunnel using preshared keys to join a private
network inside the Gateway and a Windows 2000 or XP computer. You can find detailed information on
configuring the Windows 2000 server at the Microsoft website:

Microsoft KB Q252735 - How to Configure IPSec Tunneling in Windows 2000
http://support.microsoft.com/support/kb/articles/Q252/7/35.asp

Microsoft KB Q257225 - Basic IPSec Troubleshooting in Windows 2000
http://support.microsoft.com/support/kb/articles/Q257/2/25.asp

Environment

The IP addresses and other specifics mentioned in this appendix are for illustration purposes only.

Windows 2000 or Windows XP
IP Address: 140.111.1.2 <= User ISP provides IP Address; this is only an example.

Subnet Mask: 255.255.255.0

AG041

WAN IP Address: 140.111.1.1 <= User ISP provides IP Address; this is only an example.

Subnet Mask: 255.255.255.0
LAN IP Address: 192.168.1.1
Subnet Mask: 255.255.255.0

NOTE: Keep a record of any changes you make. Those
changes will be identical in the Windows “secpol”
application and the Router’s Web-Based Utility.

NOTE: This section’s instructions and figures refer to
the Router. Substitute “Gateway” for “Router”. Also, the
text on your screen may differ from the text in your
instructions for “OK or Close”; click the appropriate
button on your screen.
