Impinger X2 – Analog Service Manual – Dom & Int’l
38
IMPINGER X2 OVENS
CONVEYOR, DUAL BELT
LETTER
PART NUMBER
DESCRIPTION
A
100403103
Take off shelf, infeed side
100403101
Take off shelf, out take side
B
100403107
Pan stop, zero stop
C
100403710
Crumb pan (bottom conveyor only)
D
405849-2EP
Connecting link
E
100405847
405849EP
100405844
Conveyor belt, complete, 3240
Conveyor belt, complete, 3262
Conveyor belt, complete, 3270
405849-1EP
Conveyor belt, 1ft. section
F
390050
Bushing assembly, dual belt
G
100404710
Shaft, idle end
H
406000EP
Roller, smooth
I
405900EP
Roller, notched
J
300403331
100403361
200403390
Frame assembly, upper conveyor, 3240
Frame assembly, upper conveyor, 3262
Frame assembly, upper conveyor, 3270
300403330
100403360
200403380
Frame assembly, lower conveyor, 3240
Frame assembly, lower conveyor, 3262
Frame assembly, lower conveyor, 3270
K
508103EP
Coupling half
L
100404810
Shaft, drive
