Impinger X2 – Analog Service Manual – Dom & Int’l 34
IMPINGER X2 OVENS
BURNER/DRIVE END
LETTER PART NUMBER DESCRIPTION
A 7007124 Flange, burner
B 390048 Heat slinger, 3240
390047 Heat slinger, 3262, 3270
C 507500EP Bearing, drive end
D 501260EP Motor, burner blower
E 501250-8EP Relay, time delay
F 369531 Transformer, 120/24VAC
G 369142 Flame target
H 501250-1EP Igniter/sensor assy.
I 100501271 Shield, pilot
J Cable, spark
K 2605078 Orifice, pilot, Nat.
Orifice, pilot, L.P.
L 370059 Manifold, burner
M 369398 Valve, temperature regulation (120 VAC)
370186 Valve, temperature regulation (CE ovens, 220VAC)
N 50150-5EP Valve, main gas (24VAC)
370433 Valve, main gas (CE ovens, 220 VAC)
O 2605080 Orifice, main burner, Nat.
Orifice, Main burner, L.P.
P 369400 Moveable plate, air shutter
Q 369399 Air shutter
