Impinger X2 – Analog Service Manual – Dom & Int’l 30
IMPINGER X2 OVENS
OVEN CAVITY
LETTER PART NUMBER DESCRIPTION
A 9004435 Guard, shaft – 3262
9004419 Guard, shaft – 3270
B 4071215 Housing, blower
C 100601417 Air return plate, right – 3240, 3262
200601417 Air return plate, right – 3270
D 100601417 Air return plate, left – 3240, 3262
200601417 Air return plate, left – 3270
E 100601394 Air dam, upper
F 100110224 Close-off, upper plenum
G 100102601 Support, oven cavity
H 100106000 Plate, connector
I 300601280 Extension tube, burner – 3240
100601280 Extension tube, burner – 3262
200601280 Extension tube, burner – 3270
J 300601328 Shaft, blower wheel assy. – 3240
100601328 Shaft, blower wheel assy. – 3262
200601328 Shaft, blower wheel assy. – 3270
K 3001401011 Oven back – 3240
1001401011 Oven back – 3262
2001401011 Oven back – 3270
L 100601334/100601336 Burner heat shield, outer, inner
M 100601324 Burner opening cover
N 390048 Heat slinger – 3240
390047 Heat slinger – 3262, 3270
O 390063 Bearing, idler
P 9004431 Top cover, idler end
Q 100120224 Cover, idler end
R 100110204 Flange, thermocouple mount
S 7007374 Guard, center air return – 3262
7007375 Guard, center air return - 3270
