Land Pride RCM5510 - Manual (Page 14)

Revision Comments Part Description Part No. Ref.
RCM5510 RCM6510 PTO 2500 CAT.5 1000 1 3/8-21 826-247C 36.
RCM5510 RCM6510 S/N ______+ PTO CV 1000 1-3/4 NO CLUTCH 826-645C 36.
RCM5510 RCM6510 S/N ______- RPBY 826-645C 826-499C 36.
540 RPM & 1000 RPM CAT 5 PTO E60 X 21.7 1280NM CLUTCH 826-478C 37.
540 RPM CAT 4 PTO INT. CAT.4 540W/CLUTCH 826-183C 37.
1000 RPM CAT 4 PTO INT. CAT.4 1000W/CLUTCH 826-184C 37.
COMER U0.125.7003.00 OIL PLUG 826-486C 38.
COMER VENT #8.6.7.00269 826-497C 39.
RC5510 RC6510 DIV BOX 540RPM 1 3/4-20 826-520C 40.
RCM5510 RCM6510 DIV BOX 1000RPM 1 3/4-20 826-521C 40.
BUSHING CYL 1 1/4 X 1 X 1 890-005C 41.
NUT HEX FLG TOP LK 3/4-10 PLT 803-299C 42.
ITG Gearbox HHCS 5/8-11X1 3/4 GR5 802-053C 43.
Omni Grearbox S/N 584787+ HHCS 3/4-10X1 3/4 GR5 802-392C 43.
ITG Gearbox WASHER LOCK SPRING 5/8 PLT 804-022C 44.
Omni Grearbox S/N 584787+ WASHER LOCK SPRING 3/4 PLT 804-023C 44.
S/N 584787+ PLATE, DIV. BOX SUPPORT 318-746D 45.
S/N 584787+ HHCS 5/8-11X1 3/4 GR5 802-053C 46.
14 RC5510, RCM5510, RC6510 & RCM6510 Rotary Cutters 330-057P 06/14/13
Table of Contents Part Number Index
Land Pride Section 2: Decks
Deck Center Section (continued)
Applies to RC5510, RC6510, RCM5510, RCM6510
