Rev. A 9/07 4 2085454 Rev. A 9/07 5 2085454
INSTRUCCIONES IMPORTANTES -
MANUAL DE OPERACIÓN
LEA Y GUARDE ESTAS INSTRUCCIONES
LEA CUIDADOSAMENTE LAS INSTRUCCIONES ANTES DE
INTENTAR ARMAR, INSTALAR, USAR O DAR MANTENIMIENTO
AL PRODUCTO DESCRITO.
PROTÉJASE A SÍ MISMO Y A LOS DEMÁS CUMPLIENDO CON
TODA LA INFORMACIÓN DE SEGURIDAD. EL NO SEGUIR
LAS INSTRUCCIONES PODRÍA RESULTAR EN LESIONES
PERSONALES Y/O DAÑOS A LA PROPIEDAD.
CONSERVE LAS INSTRUCCIONES COMO FUTURA REFERENCIA.
CONSERVE ESTAS INSTRUCCIONES
VENTILADOR DE PEDESTAL DE 45,7 CM
CYCLONE® AJUSTABLE
MODELO 1825
MAINTENANCE
SERVICING:
All other servicing, with the exception of general
user-maintenance, should be performed by an authorized service
representative. Call 1-800-233-0268, Monday through Friday, be-
tween the hours of 8:00 a.m. and 5:00 p.m. EST for the location of
your nearest service center.
STORAGE:
Store the Fan with these instructions, in the original
carton in a cool, dry place.
LUBRICATION:
Motor is permanently lubricated.
OPERATION
OSCILLATION: Push down oscillation knob on motor housing to
make fan head move from side to side.
(Figures 10 and 11)
TILTING: This Fan is equipped with
a multi-angle Fan Head for Whole-
Room Air Circulation. Follow the
steps below to properly adjust the
"tilt angle" of your Fan. (Figure 13)
1. Place one hand on the pole just
under the Fan Neck.
2. Place your other hand on top of
Fan.
3. Gently push or pull the Fan
Head until it is in the desired
position.
SPEED: Control fan speed with
Speed Switch at rear of motor.
(Figure 12)
3 - High Speed
2 - Medium Speed
1 - Low Speed
To turn the Fan OFF, turn the Power/
Speed Knob to OFF (0) and unplug
the unit from the electrical outlet.
Down: Oscillate Up: Stationary
Figure 10 Figure 11
Figure 12
0
1
2
3
Speed
Switch
Oscillation
Knob
Figure 13
1. Place the Fan on a firm and level surface.
CAUTION:
Plastic or rubber tabs, like the feet on this unit, may
stick to furniture surfaces and/or hardwood floors. The unit may leave
a residue that could darken, stain or leave permanent blemishes on
the finish of certain furniture surfaces, including wood surfaces, and/or
hardwood floors.
2. Plug the cord set into a 120 volt outlet.
Be sure that the plug fits tightly into outlet.
When plugs fit loosely into receptacles, they may slip
partially or completely out of the receptacle with only
the slight movement of the attached cord. Receptacles
in this condition may overheat and pose a serious fire
hazard; if covered by a curtain or drape, the fire hazard
is even greater.
- Always unplug the cord before moving, servicing or
cleaning.
- NEVER place the Fan in or near water.
- Disassembled grills may be immersed to be cleaned with a
mild detergent and water.Wipe all other parts with soft cloth
moistened with water and mild detergent only. DRY ALL
PARTS COMPLETELY BEFORE REASSEMBLING. After
any maintenance or servicing, completely reassemble unit
as described in this instruction manual before reconnecting
to the power supply.
- NEVER use ALCOHOL or SOLVENTS such as gasoline,
benzene, paint thinner, or other harsh cleaners.
To reduce the risk of electrical shock and fire
please observe the following instructions:
Este Ventilador es sólo para uso residencial.
No está destinado para ser usado en instalaciones comerciales, industriales o agricultura.
LASKO PRODUCTS, INC. LIMITED WARRANTY
(NOT VALID IN MEXICO)
WHAT THIS WARRANTY COVERS: This product is warranted against defects in workmanship and/or materials.
HOW LONG THIS WARRANTY LASTS: This warranty extends only to the original purchaser of the product and lasts for one (1) year from the date of original
purchase or until the original purchaser of the product sells or transfers the product, whichever first occurs.
WHAT LASKO WILL DO: During the warranty period, Lasko will, at its sole option, repair or replace any part or parts that prove to be defective or replace the
whole product with the same or comparable model.
WHAT THIS WARRANTY DOES NOT COVER: This warranty does not apply if the product was damaged or failed because of accident, improper handling
or operation, shipping damage, abuse, misuse, unauthorized repairs made or attempted, or the use of the product for commercial or nonresidential service.
This warranty does not cover shipping costs for the return of products to Lasko for repair or replacement. Lasko will pay return shipping charges from Lasko
following warranty repairs or replacement
ANY AND ALL WARRANTIES, EXPRESSED OR IMPLIED (INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTY OF MERCHANTABILITY),
LAST ONE YEAR FROM THE DATE OF ORIGINAL PURCHASE OR UNTIL THE ORIGINAL PURCHASER OF THE PRODUCT SELLS OR TRANSFERS
THE PRODUCT, WHICHEVER FIRST OCCURS AND IN NO EVENT SHALL LASKO’S LIABILITY UNDER ANY EXPRESS OR IMPLIED WARRANTY
INCLUDE (I) INCIDENTAL OR CONSEQUENTIAL DAMAGES FROM ANY CAUSE WHATSOEVER, OR (II) REPLACMENT OR REPAIR OF ANY
HOUSE FUSES, CIRCUIT BREAKERS OR RECEPTACLES. NOTWITHSTANDING ANYTHING TO THE CONTRARY, IN NO EVENT SHALL LASKO’S
LIABILITY UNDER ANY EXPRESS OR IMPLIED WARRANTY EXCEED THE PURCHASE PRICE OF THE PRODUCT AND ANY SUCH LIABILITY SHALL
TERMINATE UPON THE EXPIRATION OF THE WARRANTY PERIOD.
Some states and provinces do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages,
so these exclusions or limitations may not apply to you. This warranty gives you specific legal rights. You may also have other rights which vary from state to
state and province to province.
Proof of purchase is required before a warranty claim will be accepted.
CUSTOMER SERVICE:
Toll-Free (800) 233-0268. Email: [email protected]
Our Customer Service team is available to assist you with product questions, service center locations, and replacement parts. They can be reached Monday
through Friday, 8am-5pm Eastern. Please have your model number available, as well as the type and style (located on the underside of your product). Please
do not return product to place of purchase.
Customer Service Dept., 820 Lincoln Ave., West Chester, PA 19380 (Please do not send product to this location)
www.laskoproducts.com
PARTS FOR DISCONTINUED, OBSOLETE AND CERTAIN OTHER PRODUCTS MAY NOT BE AVAILABLE. DUE TO SAFETY REASONS, MANY ELECTRONIC
COMPONENTS AND MOST HEATER COMPONENTS ARE NOT AVAILABLE TO CONSUMERS FOR INSTALLATION OR REPLACEMENT.
