When connecting devices to the SCS3230, be sure to use Lightwave Communications
cables and adapters to ensure the proper transmission of data signals. If a device has
an RJ45 serial port, use the manufacturer's cable included with the equipment to
convert the RJ45 serial connector to a DB9 or DB25 connector, and then use a
Lightwave Communications adapter to convert back to RJ45 to attach to the device
port. Directly connecting the RJ45 port on the SCS3230 to the RJ45 port on a third-
party device may not allow for the proper transmission of data signals.
SCS3230 serial port default settings
Port Type
Baud Rate Data Bits Parity Stop Bits Port Configuration
TERM 9600 (fixed) 8 None 1 DCE
Terminal 38400 8 None 1 DCE
Device 9600 8 None 1 DCE
5.1 Terminal Card
Terminal Card typical adapters and port configuration:
System Type
Adapter Part Number Port Configuration
Wyse 50 / 60 200.0066 DCE
DEC VT330, PC (25pin) 200.0067 DCE
PC (9pin) 200.0070 DCE
Materials:
•
SCS3230 terminal port
•
terminal or computer with RS-232 serial port
•
RJ45-terminated Cat 5 cable (standard LAN cable)
•
Lightwave adapter for terminal serial port
1.
Attach the Lightwave adapter to the terminal or computer serial port.
2. Connect the Cat 5 cable to the adapter. Connect the other end to the SCS3230
terminal port.
3.
Turn on the terminal or start the computer’s communication program. Make sure that
the communication parameters of the terminal or computer match those of the terminal
port.
