F-12

DIAGRAMS

F-12

CV-400-I

DIMENSION PRINT

5-18-90J

N.A.

N.A.

N.A.

N.A.

FOUR SLOTS IN BASE FOR MOUNTING

WELDER DOWN USING 5/16 SCREWS

1.68

N.B.

N.B. HANDLE CONFIGURATION ON EARLIER MODELS.

20.05 (509)

19.65 (499)

19.20 (487)

41.58 (1056)

26.00 (660)

3.61 (91)

12.60 (320)

(42.7)

11.99 (304)

3.90 (99)

.28

(7.0)

1.00 (25.4)

23.62 (600)

6.20 (157)

30.95

(786)

1.38

(35)

17.25 (438) (CENTERED)

21.50 (546)

24.75

(628)

M15665
