Mounting Options
6
Mounting Options
You can mount the LA-316 to a microphone stand, or you can use the U bracket to directly mount it
to any vertical or horizontal surface.
Microphone Stand Mounting
· Locate the microphone stand nut in the included poly bag,
or use the nut that comes with the microphone stand.
· Remove the leatherette handle cover.
· Position the U bracket so that it will hold the LA-316
upright on the microphone stand.
· Screw the nut onto the stand and tighten with a wrench.
Vertical / Horizontal Permanent Mounting
· Remove the U bracket by loosening the two screws on both sides
of the LA-316. Be careful not to lose the washers.
· Using the two self-tapping screws and (if necessary) hollow wall
anchors, mount the bracket to any surface.
· Position the LA-316 into the bracket and tighten the two screws.
LA-316 Mounting Options
