Listen Technologies LA-316 - Manual (Page 7)

Carrying Options
5
Carrying Options
The U bracket that comes standard with the LA-316 can be used to permanently mount
the unit, set the unit at an angle on a desktop, or be used as a carrying handle.
To change the position of the U bracket:
· Loosen the two screws (the large knobs) on both sides of the LR-600.
Note that you have to loosen the screws considerably to allow the bracket to swivel.
· Rotate the bracket to the desired position.
· Re-tighten the two screws.
Carrying Options
Loosen knobs to rotate
handle/bracket.
LA-316_2005_04_28.qxp 4/28/2005 8:22 AM Page 7
