Listen Technologies LA-122 User Manual
La-122 universal antenna kit

D o n ' t m i s s a s i n g l e s o u n d .
LA-122 Universal Antenna Kit
updated 07.20.05
Listen
®
and the Listen logo are registered trademarks of Listen Technologies Corporation
List e n Te c h no l o g i es C o r p o r a tio n
8535 South 700 West, Suite A
Sandy, UT 84070-2515 U.S.A.
Phone: 1.801.233.8992 or 1.800.330.0891
Fax: 1.801.233.8995
Email: [email protected]
Listen's LA-122 Universal Antenna Kit is the ONE solution for all
your remote antenna needs. The kit contains both 72 MHz and
216 MHz antennas; monopole and dipole antenna options; and
hardware to mount on a wall, on electrical boxes, on a
horizontal surface (flat and inverse), inside a wall or ceiling. It
can also be mast mounted (hardware not included). See the list below for a few
of the possibilities.
• Includes both 72 MHz and 216 MHz antennas
• Monopole and dipole antenna options
included
• Rigid and flexible radials are included
• All hardware to mount on a wall, on electrical
boxes, on a horizontal surface (flat and
inverse), inside a wall or ceiling is included
Specify Par t
Number
LA-122
Mounting Possibilities
1. Wall mount dipole* or monopole
2. Flexible dipole (in a wall or rafter area)
3. Horizontal surface monopole (up or down)
4. Mast or conduit mount
5. Electrical box monopole inverse ceiling mount
6. Electrical box wall mount dipole* or monopole (Single or double gang)
*Dipole antenna configuration recommended for bet range/coverage. Should be oriented vertically for best results. Not weather proof or wind
resistant. All of this and other information is available at www.ListenTech.com
1
2
3
4
5
6
