Speaker Connection
4
Connecting the Expansion Speaker
Connect the speaker wire to the red and black terminals on the
back of the LA-316. To do this, press the spring loaded clip down
and insert wire as shown below.
Connect the other end of speaker wire to an LR-100 Receiver/Amplifier, LR-600 Receiver/Speaker,
or any other source. Make sure to observe correct polarity of wires.
LA-316
LR-600
