Land Pride Powered Rakes PR1672 User Manual
Page 26
24
Section 6: Features & Benefits
PR1660, PR1672 & PR1690 Powered Rakes 314-216M
6/12/13
Section 6: Features & Benefits
PR16 Series (3-Point)
Features
Benefits
Working widths
60", 72" & 90"
Tractor Horsepower Range
PR1660 = 25 - 40 HP
PR1672 = 25 - 40 HP
PR1690 = 35 - 75 HP
Cat. 3 drivelines with
slip-clutch on second
driveline
Slip-clutch offers protection to the gearbox and entire power train when a tough obstruction
is encountered with the roller.
6" x 3" x 1/4" Tube Frames
Superior in strength.
3/4" x 1 1/2" Carbide Tipped
Studs
Carbide tipped studs are very tough, used in the mining industry, this offers a long life to
the studs. Studs can be replaced one at a time.
15 Degrees left or right
angling
By angling either direction, the user has many options on what direction to work his area.
Gauge wheels with sealant
Easy to adjust vertically to set working depth. Has tall and wide tires that keep turning in
fluffy soil. Sealant helps seal against punctures.
End plates with storage
End plates can be used to hold dirt to aid in filling low spots. Easily store the end plates on
the Powered Rake so that they are always with the Rake when needed.
Material control deflector
Material control deflector is used to determine what size of material to let pass through the
roller and what size to move out.
#50 Double continuous roller
chain
Double roller chain can take the fluctuation loads from the roller due to varying ground
conditions.
Cast Iron chain guard housing
Strong enough to protect chain in harsh conditions.
Drive chain enclosed in oil
bath with drain plug
Oil keeps the chain and sprockets lubricated to keep abrasion to a minimum. Easy to
maintain and change oil level.
Replaceable skid shoes
Skid shoes protect larger and vital parts of the unit. As they wear due to soil contact, they
can easily be replaced.
5 Year gearbox warranty
Shows our confidence in the gearbox integrity.
Quick Hitch
Can be used with Land Pride Quick-Hitch. (May need extra driveline.)
