8 5 0 i R U s e r M a n u a l
850iR User Manual | 8
1.
CHARGE INDICATORS:
The light
glows RED while the REDMIKE is
charging. When fully charged, the
light will glow GREEN.
2.
DC POWER PORT:
Connect the DC
power cord here.
3.
OPTIONAL CHARGING PORT:
Plug the
charging cord for the optional LT-71 or
the HM-70 microphones here.
CRADLE CHARGER CONTROLS AND CONNECTIONS
1
2
3
