Lenovo TS130 User Manual
Page 49
9. Slide the new hard disk drive with the blue bracket into the secondary hard disk drive cage until
it snaps into position.
10. Slide the hard disk drive cage with the new hard disk drive into the chassis until it is directly underneath
the metal tab
1
.
Figure 27. Installing the secondary hard disk drive
Chapter 5
.
Installing, removing, or replacing hardware
37
