60
Technical appendix
Type UFS 702si UFS 702sw
Order no. 20210079 20210080
Colour Silver Black
RF properties
Input frequency range
MHz 950-2150
Input level range dBµV 44-83
Reception threshold (EB/NO) < 4.5
TV system, Video
Modulation, FEC, demultiplexer
DVB-S standard
Video resolution CCIR 601 (720 x 576 lines)
Input data rate MSymb/s 2-45
Video decoding MPEG-1 and 2 compatible
Bit rate MBit/s 1.5-15
Frequency range MHz 0.02-5
Output voltage V
ss
1
S/N dB > 53
TV system, Audio
Audio decoding
MPEG-1 and 2, Layer 1 and 2
Sampling rate kHz 32/44,1/48
Frequency range kHz 0.04-20
Output voltage mV
ss
Typical 770
S/N dB > 65
Memory
Flash RAM
MB 2
SDRAM MB 8
Processor clock speed MHz 150
Power supply
Power supply voltage
V/Hz 230/50 ± 10 %
Power consumption (power/standby) W < 22/< 2
LNB supply vert./horiz. V / mA 14/18/Max. 400
Control signal kHz 22; DiSEqC™1.1; UFO ® micro
Connections
Sat IF input/output
2 x F socket
TV/VCR output 2 x Scart socket
Audio output (analogue) 2 x Cinch socket
Audio digital output (electrical) Cinch socket
Audio digital output (optical) Standard OWG (IEC 952)
Data port RJ 11 socket
General
Ambient temperature limit
°C +5 to +40
Unit dimensions mm 280 x 50 x 180
Weight kg 1.2
