Technical Appendix
89
Connections
2 Sat signal inputs/outputs
(looped-through)
4 x F socket
TV Connection Scart socket, 21-pin
VCR/AUX Connection Scart socket, 21-pin
Video/audio output 3 x Cinch socket
Digital audio output Optical standard fibre-optic socket
Electrical cinch socket
Digital audio format Dolby Digital/AC 3 Compressed PCM
MPEG Stereo PCM
Data port for service RS 232 Sub D 9-pin/USB 2.0
General
Unit dimensions (W/H/D) 335 x 63 x 280 mm
Weight approx. 2.75 kg
Temperature range
Ambient temperature +5 °C to +40 °C
