3 .Package Contents
z User
Manual.
z Power Adapter.
z 10/100/1000Mbps Gigabit Ethernet Switch.
4 . Hardware Introduction
4.1 Front Panel
POWER LED
This LED light is on when power is present.
8 Port LED
Indicates the status of each of the 8 ports.
Speed 100 Mbps LED
A green LED indicates the speed is 100 Mbps.
Speed 1000 Mbps LED
An orange LED indicates the speed is 1000 Mbps.
Link/Activity LED
There is a link when the LED light is lit, there is an activity when the LED
blinks
