25
BOX SETTINGS
VIDEO AND AUDIO SETTINGS
Screen Format:
Select your TV's format here. Either 4:3 (letterbox 14:9), 4:3 (letterbox 16:9), 4:3 (Pan & Scan/CCO) or
16:9/wide-screen TV
Picture Scaling:
Here select how the receiver should display a picture which does not match its pre-set format.
For screen format 4:3: Either “Letterbox 14:9”, “Letterbox 16:9”, or “Pan & Scan/CCO”For screen format 16:9
/ wide-screen TV: Either “Stretched”, “Zoom” or “Pillarbox”
TV Output Format:
Select the type of video signal that should be present at the TV Scart socket. Select the signal that your TV
set can process.
Refer to the operating instructions for your television set!
You can choose from the following settings: RGB (Red/Green/Blue signal), S-video (luminance/chrominance)
and CVBS (Colour Video Baseband Signal)
VCR Output Format:
Select the type of video signal that should be present at the VCR Scart socket. Select the signal that your
external recorder can process. Available options: S-video and CVBS
Refer to the operating instructions for your recorder!
AFD Automatic:
This function corrects the screen format automatically if the broadcast screen format varies from that
displayed
Teletext:
You can select whether the Teletext is controlled by the TV remote control (external, Teletext signal is
processed by the TV set) or by the receiver remote control (internal, Teletext signal is processed by the
receiver).
Also pay attention to the
bars at the bottom of the on-
screen display! These provide
information on what to do next.
Use the buttons to select the
line you want to change. Use
the buttons to make the
changes.
