Installation
8
• Install the alarm on the mounting plate and rotate the
alarm in the direction of the “ON” arrow on the cover
until the alarm ratchets into place (Image 3D). This
ratcheting function allows for aesthetic alignment.
Note: The alarm will attach to the mounting plate in 4
positions (every 90°).
A
A
IMAGE 3A
IMAGE 3C
IMAGE 3D
“A” LINE
ALIGNMENT MARKS
WALL MOUNTING
POSITION
ROTATE TO MOUNT OR
TO REMOVE
IMAGE 3B
Install
Remove
