G-Analyzer Operation
Function of KDC-X792
G-Analyzer Control
You can adjust following G-Analyzer Control items ;
Item
Setting/ Page
Setting overview
> “GMENU”
G- Graphic/ Downloaded
G-Graphic*
1
/ G-Meter*
2
/
G-Counter*
2
G-Analyzer display
Selection
> “GMA” > “STOP.
W”
(page 13)
G-Analyzer Stop Watch
> “GMA” > “HP”
(page 14)
G-Analyzer Horsepower
Analysis
> “GMA” > “RESET” (page 14)
G-Analyzer Reset
> “GMA” > “LEVEL” Level1 – 3*
3
G-Counter Level seting
> “GMA” > “CAL”*
(page 13)
G-Analyzer Calibration
setup
> “GMA” > “HP
SET” *
(page 12)
G-Analyzer vehicle setup
* Can be set in standby state.
*
1
G-Graphic can be switched to customized pictures. Refer
to
*
2
The value of G-Meter display and G-Counter display can
be reset by
*
3
Calibrating G-Point. Setting the level according to the
kinds of vehicles. In the case of driving situations calling
for few accelerations, set the G-Point up to “Level1”. In
the case of frequent accelerations, set it up to “Level3”.
1
Enter Display Control mode (In Display Type F)
Select “DISP”.
For how to select Function Control item, refer to
2
Enter G-Analyzer item mode
Turn the Control knob or push it towards left
or right.
Press the Control knob.
3
Select the G-Analyzer item you want to set
Turn the Control knob or push it towards left
or right.
4
Exit G-Analyzer item mode
Press the Control knob.
In Standby mode
G-Analyzer Vehicle Setup
Enter vehicle weight or class to calculate
horsepower.
1
Enter G-Analyzer vehicle weight setup
mode (In Display Type F)
Select “DISP” > “GMA” > “HP SET” > “WEIGHT”.
For how to select Function Control item, refer to
“WEIGHT INPUT” is displayed.
2
Enter weight input
Operation type
Operation
Select the weight numbers
Turn the Control knob.
Select the digits to enter
Push the Control knob towards right
or left.
3
Exit G-Analyzer vehicle wight setup mode
Press the Control knob.
4
Enter G-Analyzer vehicle class setup mode
Select “DISP” > “GMA” > “HP SET” > “CLASS”.
“CLASS SELECT” is displayed.
5
Select vehicle class
Turn the Control knob.
“Mid Size”/ “Full Size”/ “SUV”/ “Van/ Mini-Van”/
“Pickup Truck”/ “Sporty”/ “Compact”
6
Exit G-Analyzer vehicle class setup mode
Press the Control knob.
