KODAK i600 Series Scanners
KODAK Service & Support makes
sure your uptime stays up.
As one of the largest and most expe-
rienced service organisations in the
document imaging industry, KODAK
Service
& Support provides peace-of-
mind coverage with more than
2,000 highly trained and certified
field engineers worldwide. Plus a
global network of parts and distribu-
tion, exceptional on-site and help
desk service, and a variety of service
plans and options to fit the way you
work. And it all comes with customer
satisfaction ratings that are consis-
tently above 95%. With KODAK
Service
& Support, the help you need
is always close at hand.
Specifications
Recommended daily volume Up to 60,000 pages per day
Throughput speeds i610*/i620 80 ppm (up to 320 ipm**)
(200 dpi, landscape, i640 100 ppm (up to 400 ipm)
letter size documents) i660 120 ppm (up to 480 ipm)
ppm = pages per minute
ipm=images per minute
Scanning technology Dual Tricolor Plus CCD
Greyscale output bit depth is 256 levels (8-bit)
Colour* capture bit depth is 40-bit (10 bits per red, green, blue and black channels)
Colour* output bit depth is 24-bit
Optical resolution 300 dpi
Illumination Dual long-life Xenon lamps per side, mercury-free
Output resolution Colour*: 100/150/200/240/300 dpi
Greyscale: 100/150/200/240/300 dpi
Bitonal: 200/240/300/400 dpi
Maximum document size 305 x 863 mm
Minimum document size 64 x 64 mm
Paper thickness and weight With Standard feeder:
45 g/m 2 bond to 200 g/m 2 index
With Ultra-Lightweight feeder accessory:
25 g/m 2 rice paper to 75 g/m 2 bond
Automatic feeder/elevator 500-sheet elevator-design document feeder with four settings:
continuous feed, 100-sheet, 250-sheet and full 500-sheet batches
Multi-feed detection 3-D multi-feed detection with ultrasonic technology; three ultrasonic sensors
that can work together or independently
Connectivity IEEE-1394 (F IRE W IRE ) Interface, 6-pin connector; IEEE-1394 card and cable included
Interface support TWAIN and ISIS drivers (included); KODAK Capture Software; VRS Ready
Imaging features Perfect Page Scanning with iThresholding, automatic colour* detection, autocrop,
(in the scanner) aggressive crop, deskew, electronic colour* dropout, orthogonal rotation, error
diffusion, halftone removal, noise removal, toggle patch
On-board compression CCITT Group IV; JPEG or uncompressed output
File format outputs JPEG (for colour* and greyscale images); TIFF (for bitonal images)
Warranty Standard 12 months. Extended: 3 year, on-site option
Electrical requirements 100-240 V, 50/60 Hz
Power consumption 178.4 watts maximum
Environmental factors ENERGY STAR qualified scanners; D.O.C. Executive Order 13221 Compliant
Section 508 Compliant; Mercury-free Xenon lamps;
operating temperature: 15–35°C; operating humidity: 15% to 76% RH
Acoustical noise (operator Standby mode: <42 dB(A)
position sound pressure level) Operating mode: <61 dB(A)
Recommended PC configuration PENTIUM IV 2.4 GHz processor with 512 MB RAM
Supported operating systems WINDOWS 98SE, Me, 2000, XP
Approvals and product AS/NZS 3548 Class A (C-Tick Mark), CAN/CSA-C22.2 No. 60950 (C-UL Mark),
certifications Canada ICES – 003 Issue 3 (Class A), GB4943, GB9254 (Class A), GB 17625.1
Harmonics, (CCC “S&E” Mark), EN 55022 ITE Emissions (Class B), EN 61000-3-2
Powerline Harmonics, EN 61000-3-3 Flicker, EN 55024 ITE Immunity (CE Mark),
EN 60950 (TUV GS Mark), IEC 60950, CISPR 22 Class B, VCCI (Class A), CNS
13438 (Class A) (BSMI Mark), UL 60950 (UL Mark), CFR 47 Part 15 Subpart B
(FCC Class A)
Consumables available Feeder consumables kit, extra-large feeder consumables kit, imaging guide set,
printer ink cartridge and carrier, transport cleaning sheets, roller cleaning pads, print-
er ink blotters, staticide wipes, calibration targets, black imaging background
Accessories Ultra-lightweight feed module; White imaging background; Manual feeder
Height: 40 cm
Width: 61 cm
Depth: 77 cm
Weight: 38.6 kg
* the i610 model does not scan in colour
** ipm speeds based on simultaneous output of four compressed images for each document scanned—bitonal and colour or bitonal and greyscale
Specifications subject to change without notice. Throughput speeds may vary depending on your choice of driver, application software,
operating system and PC.
