28 KODAK EKTAGRAPHIC III Slide Projector
Troubleshooting
Slide fails to drop into projection
position Tray base plate not properly indexed Rotate the tray base plate until
it locks into position.
Tray not properly positioned on
projector Reposition tray on projector.
Slide mount warped or frayed at
corners slide. Straighten mount or remount
slide.
Projector not level or tilted too high Set projector on a stand equal
with center of screen.
Uneven illumination on screen Projection lamp not fully seated Check lamp.
Condenser lens not installed or not
positioned properly in mount Check condenser lens.
Slide mount not seated properly in
projector gate Check slide position and slide-
mount condition.
Projector won't cycle to next slide Tray not properly positioned Reposition tray.
Slide or foreign object stuck in gate See " Clearing a Gate Jam " on
page 18 .
Program does not start with the with
the correct slide Tray number is not aligned with the
with the raised index mark. Reposition tray (see “ Tray ” on
page 9 ).
PROBLEM CAUSE CORRECTION
