Specifications:
Camera Type: Interchangeable-lens digital SLR camera
Lens Mount: Minolta A-type bayonet mount
Image Capture: Total pixels: 6.3 million, effective pixels: 6.1 million
CCD (23.5mm x 15.7mm, Interline primary color, interlace scan
Sensitivity: Auto and 100, 200, 400, 800, 1600, and 3200 ISO
equivalents
Aspect Ratio: 3:2
Recording: Recording Media: Type I and Type II CompactFlash cards,
Microdrive, SD Memory Cards, and MultiMedia Cards with optional
CompactFlash Adapter SD-SF
File Format: JPEG, RAW, RAW+JPEG (DCF 2.0 compliant, DPOF
(supported by printing functions in ver/1.1), Exif 2.2)
Number of Recorded Pixels: L: 3008 x 2000, M: 2256 x 1496,
S:1504 x 1000
Storage Capacity: Approximate storage capacity of a 256MB
CompactFlash Card:
L M S
RAW 26 frames — —
RAW+JPEG 19 frames 21 frames 23 frames
Extra Fine 41 frames 72 frames 157 frames
Fine 81 frames 141 frames 292 frames
Standard 1138 frames 1235 frames 463 frames
Color Modes: Natural: sRGB, Natural +: sRGB, Adobe RGB
Image Quality Modes: Standard, Fine, Extra Fine, RAW, RAW+JPEG
(Fine)
Image Correction: Contrast, Color saturation, Sharpness, Hue (5 levels)
Noise Reduction: Available (at shutter speed longer than 1 sec.,
ON/OFF selectable)
Delete Function: Single frame, Marked frames, or All frames in a folder
in card can be deleted.
White Balance Control: Automatic, Preset (Daylight, Shade, Cloudy,
Tungsten, Fluorescent, Flash), Custom, Color temperature setting
available
Playback: LCD monitor: 2.5-inch TFT color; Total pixels: 207,000;
Navigation system: (Enlarged display, Automatic rotate function); Number
of frame displayed: 1, Index (4, 9, 16 selectable); Display mode: Image
only, Image + text, Image + text + histogram; Enlarged playback (up to
approx. 5x), Luminance limit Display, File browser, Slideshow, Instant
bracket playback
Autofocus System: Through-the-lens (TTL) phase-detection system
AF Sensors: CCD line sensors (9 points, 8 lines with center cross-hair
sensor)
AF Sensitivity Range: EV -1–EV18 (ISO 100)
Autofocus Area: Wide focus area, any local focus area is selectable
from 9 point sensors
Focus Modes: Autofocus/Manual focus can be selected.
Autofocus Modes: Single-shot AF, Continuous AF, Automatic Autofocus
(DMF is selectable in menu); Predictive focus control for moving
subjects; Auto-tracking focus point display
Focus Lock: By pressing the shutter release button halfway down
AF Illuminator: With built-in flash, 3.3–16.4 ft.
Autoexposure System: TTL metering using 14-segment honeycomb-
pattern SPC (14-segment Honeycomb-pattern/Center-weighted/Spot
metering)
Metering Range: EV 0–20 (EV 3–20 in spot metering) *at ISO100 with
f/1.4 lens
Exposure Modes: P/Full-auto program (Programmed AE with program
shift), A (Aperture priority), S (Shutter priority), M (Manual)
Exposure Compensation: +/- 3 EV in 1/2 increments, +/- 2 EV in
1/3 increments
AE Lock: Automatically activated with AF lock, Available with
AE lock button
Flash Metering: ADI, Pre-flash TTL, Manual flash control
Guide Number: 12 (in meters at ISO 100), 17 (in meters ISO 200)
Flash Coverage: 24mm
Recycling Time: 3 sec. (approx.)
Flash Control: Manual switchover type. Lift-up for Fill Flash, push down
for Flash Cancel
Flash Modes: Fill Flash, Flash Cancel, Red-eye Reduction (pre-flash),
Wireless/Remote Off-camera Flash, Rear Flash Sync., High-Speed Sync
Flash Compensation: +/- 2 EV in 1/2 increments
Accessory External Flashes: Program Flash 5600HS(D), 3600HS(D),
2500(D), Macro Twin Flash 2400*, Macro Ring Flash 1200* with flash
sync. terminal
*Macro Flash Controller is necessary
Shutter: Electronically-controlled, vertical-traverse, focal-plane shutter
Shutter Speed Range: 30–1/4000 sec., Bulb
Flash Sync Speed: 1/160 sec. (with Anti-shake OFF), 1/125 sec. (with
Anti-shake ON)
Drive Modes: Single, Continuous; 10 sec. /2 sec. self-timer; Single
bracket, Continuous bracket
Continuous Advance: Approx 3 fps
Approximate number of frames that can be captured at one time:
L M S
RAW 9 frames - -
RAW+JPEG 9 frames 9 frames 9 frames
Extra fine 12 frames 14 frames 20 frames
Fine 15 frames 19 frames 30 frames
Standard 19 frames 26 frames 43 frames
L: 3008 x 2000, M: 2256 x 1496, S: 1504 x 1000
Exposure Bracketing: In 0.3/0.5 EV increments, 3/5 frames
Interval Recording: Interval time: 30 sec. / 1–10, 15, 20, 30, 45,
60min., 2–240 frames. Start timer is equipped (Setting: 0.5–24H, in 0.5
increments)
Other Functions: Instant playback, Customizing, Zone matching
Anti-Shake: CCD-Shift Anti-shake system with LED indicator in viewfinder;
Anti-shake effect equivalent to 2–3 steps in shutter speed (Actual effect
varies depending on shooting conditions and the lens used.)
Viewfinder: Eye-level fixed pentaprism
Focusing Screen: Spherical Acute Matte (G-type standard)
*Interchangeable focusing screens available (type M, L, ML) at service
facilities.
Field-of-View: Approx. 95%
Magnification: 0.9X (with 50mm lens focused on infinity)
Diopter Control: -3.0 to +1.0 m-1
Eye Relief: 25mm from the eyepiece, 21mm from the eyepiece frame
in -1 m-1; Eyepiece cup is removable.
Video Output: NTSC / PAL
Audio Signal: Yes
Printing Output Control: Exif Print, PRINT Image Matching II,
PictBridge
PC Interface: USB 2.0 High-Speed
Remote Function: Remote data storage available (Remote-storage
function software DiMAGE Transfer for Maxxum7D is available for free
download. (It will be released in January 2005.)
