Specifications – Konica Minolta MAXXUM 7D User Manual

Page 15

Number of Effective Pixels: 8.0 million
CCD: 2/3-type interlaced primary-color CCD
Total Pixels: 8.3 million
A/D Conversion: 12-bit
Camera Sensitivity: Auto, ISO 64, 100, 200, 400, 800 equivalents
Focal Length: 7.2 - 50.8mm (35mm equivalent: 28 - 200 mm)
Lens Construction: 16 elements in 13 groups (includes two AD glass

elements and two aspheric elements)
Maximum Aperture: f/2.8 - f/3.5
Minimum Focus Distance: 1.6 ft. (0.5m) from CCD
Macro Focus Range: At 7.2mm: 11.8 - 23.6 in. from CCD; 8.3 - 20 in. from

front of lens. At 42.7 - 50.8mm: 9.8 - 23.6 in. from CCD; 5.1 - 19.7 in. from

front of lens
Maximum Magnification: 0.177x (1: 5.65) Equivalent to 0.7x (1: 1.43)

in 35mm format
Area Covered at Maximum Magnification: 2.05 x 1.54 in.
Optical Zoom Control: Manual zoom ring
Filter Diameter: 49mm
Viewfinder Type: EVF (Electronic viewfinder)
Viewfinder LCD: 0.44 inch TFT liquid-crystal microdisplay;

Total pixels: 235,000 pixels
LCD Monitor: 1.8 inch low-temperature polysilicon TFT color;

Vari-angle: 180

Horizontally, 270

Vertically; Total pixels: 134,000

Automatic Monitor Amplification: Activates in low light.
Field of View: EVF: 100% (approx.); External LCD monitor: 100 % (approx.)
Display Mode Switch: Electronic-viewfinder display, External LCD-monitor

display
Diopter Control: -5 ~ +2 m

-1

Eye Relief: 22 mm at -1 m

-1

Shutter: CCD electronic shutter and mechanical shutter
Shutter Speed Range: 30 - 1/3200 sec. (30 - 1/1600 sec. in S, M - mode);

Bulb (max. 30 sec.)
Autofocus System: Video AF
Autofocus Areas: Wide focus area, 11 - point selectable, Spot focus point;

(Flex Focus Point control is available with the spot focus point)
Focus Modes: Autofocus: Single-shot AF, Continuous AF, Full-time AF.

Manual focus or Flex Digital Magnifier (FDM), Automatic-magnification.
Full-Time AF: With the spot focus point or Flex Focus Point; full-time AF

can be disabled.
Subject Tracking AF: With continuous AF.
Focus Lock: By pressing shutter-release button partway down.
Metering: Multi-segment, Center-weighted, Spot (center or with

Flex Focus Point)
Multi-Segment Metering: 256 segments
Exposure Control Range: Programmed AE and aperture-priority modes:

Wide: Ev -1 - 18, Telephoto: Ev -0.5 - 18; Shutter-priority and manual modes:

Wide: Ev -2 - 18, Telephoto: Ev -1.5 - 18
Exposure Modes: Programmed AE (with program shift), Aperture priority,

Shutter priority, Manual
Digital Subject Programs: Portrait, Sports action, Sunset, Night

portrait/Night View
Exposure Compensation: ± 2 Ev in 1/3 increments
AE Lock: With AE-lock button or by pressing the shutter-release button

partway down
Flash Control: Automatic and Manual flash control

Flash Range: Wide: 1.6 - 12.5 ft. (approx.);

Telephoto: 1.6 - 9.8 ft. (approx.) (Camera sensitivity: auto)
Flash Modes: Fill-flash, Red-eye reduction, Rear flash sync, Slow-sync
Flash Recycling Time: 5 sec. (approx.)
Flash Compensation: ± 2 Ev in 1/3 increments
Flash Sync Speed: All shutter speeds
External Flashes: Auto-flash metering with Program/Maxxum Flash 2500 (D),

3600HS (D), 5600HS (D), Macro Twin Flash 2400,* Macro Ring Flash 1200.*
*Macro Flash Controller is necessary.
Continuous Advance: UHS continuous advance: 10 fps (640x480); High-

speed continuous advance: 2.3 fps (max.); Standard continuous advance: 2.0

fps (max.) Actual speed may vary depending upon the subject and camera

settings.
Approximate number of frames that can be captured at one time:

3264x2448

2560x1920

2080x1560

1600x1200

640x480

RAW

5 frames

Extra fine

5 frames

Fine

5 frames

Standard

5 frames

* Actual number of images may vary depending upon the

subject and camera settings.

Exposure Bracketing: Three-frame bracket in 0.5 and 0.3 Ev increments
Digital Enhanced Bracketing: Three-frame White Balance bracket in fixed

increments.
Self-Timer: 10 sec., 2 sec. (approx.)
Remote-Control: RC-D1 Wireless Remote Included
Movie: Standard movie mode: 15 min. (max.) at 30 fps with monaural audio;

Night movie mode: 15 min. (max.) at 30 fps with monaural audio.
Audio: None with still image
Color Modes: Natural Color (sRGB), Vivid Color (sRGB), Portrait (sRGB),

Embedded Adobe RGB, Black & white (neutral and toned)
White Balance Control: Automatic; Preset (Daylight, Tungsten, Shade,

Cloudy, Flash, Fluorescent 1, and Fluorescent 2 settings); Custom (two settings)
Sharpness Settings: Three levels (Soft, Normal, Hard)
Digital Effects Control: Color saturation, Contrast compensation, Filter
Noise Reduction: User selectable dark noise reduction
Digital Zoom: 2X with still images; 4X Interpolate mode with still images
Data Imprinting: Year/month/day (Format can be changed.);

Month/day/hour/minute; Imprinting can be disabled.
Image Quality Modes: RAW, RAW+JPEG, Extra fine, Fine, Standard
Number of Recorded Pixels (Still images): 3264 x 2448, 3264 x 2176

(in 3:2 mode), 2560 x 1920, 2080 x 1560, 1600 x 1200, 640 x 480
Number of Recorded Pixels (Movie clips): 320 x 240@ 15 or 30fps in

standard and night movie modes; 640 x 480 @15 or 30fps in standard and

night movie modes; 800 x 600 @15fps in standard and night movie mode
Storage Capacity: Approximate storage capacity of a 128MB CF card:

3264x2448 2560x1920

2080x1560

1600x1200

640x480

RAW 10 frames

RAW+JPEG 9 frames 9 frames 9 frames 10 frames 10 frames

Extra fine 19 frames 32 frames 49 frames

79 frames 390 frames

Fine 31 frames 50 frames 78 frames 122 frames 558 frames

Standard 62 frames 97 frames 150 frames 229 frames 781 frames

Movie 5 minutes 55 seconds with 320x240 images @15fps

* Actual number of images may vary depending upon the subject and memory

card used.

Specifications:
