-9-
AC Power Chassis Module Specifications
Dimension
194mm x 156.6mm x 40.3mm
Installation method Plug in from system rear panel
Maintenance Modular design for easy maintenance
AC power switch System power on/off switch
AC power receptacle IEC320 type receptacle
Power status indicator Green LED
Electric
Input voltage rating 100 ~ 240VAC
Input voltage range 90 ~ 264VAC
Input frequency 47 ~ 63Hz
Input surge current 20A max. @115VAC
Efficiency 75% @115VAC full load
Output power 6 0 W
Over current protection All output with short circuit protection
Safety UL/cUL, TUV EN60950
Insulation Resistance >10M Ohm @DC500V
Dielectric withstands 1500VAC 10mA 1min.
DC Power Chassis Module Specifications
Dimension
194mm x 156.6mm x 40.3mm
Installation method Plug in from system rear panel
Maintenance Modular design for easy maintenance
DC power switch System power on/off switch
DC power receptacle Screw type terminal block
Power status indicator Green LED
Electric
Input voltage rating -48VDC
Input voltage range -48VDC +/-10%
Efficiency 73% typ. at full load
Output power 6 0 W
Protection Over voltage, over power, short circuit
Safety Meet UL1950
