KTI Networks Modular Media Converter Center System KC-1300 - Manual (Page 12)

-12-
2. Installation
2.1 Unpacking
The product package contains:
•
The system unit
•
One power cord
• One 19-inch rack mounting kit
• Operation Manual
2.2 System Units
The figure below illustrates the front view of the KC-1300 system:
Depending on the model purchased, the type and numbers of the pre-
installed media converters may be different. The figure shows a system
which is fully installed with media converters.
The following figures show the rear view of the KC-1300 system. The
main chassis provides two power chassis slots on the rear panel. Each
power chassis slot can be installed with one AC power chassis. Two
power slots design features the system a power redundant function.
