The information includes:
Column
States
Interpretation
Slot
1-16
Slot position in the system
Slot #1 - slot #16 are for MC installation
Port
A
Upper port of the MC in slot
B
Lower port of the MC in slot
Media
TX
10/100BASE-TX copper port type
T
1000BASE-T copper port type
FX
100BASE-FX Optic fiber port type
X
1000BASE-X Optic fiber port type
Link
Green
Link up
Red
Link down
Speed
10Mbps
10BASE-T
100Mbps 100BASE-TX or 100BASE-FX
1000Mbps 1000BASE-T or 1000BASE-SX/LX
Duplex
Full
Full duplex
Half
Half duplex
RTP link Green
Remote MC TP link up
Red
Remote MC TP link status not available
