-36-
The slot status definitions are:
Column States Interpretation
Slot 01-16 Slot position in the system
Slot #1 - slot #16 are for MC
Port N/A No module is installed in slot
A Upper port of the module in slot
B Lower port of the module in slot
Media N/A No MC is installed in slot.
TX 10BASE-T, 10/100BASE-TX port type
T 1000BASE-T port type
FX 100BASE-FX port type
X 1000BASE-X port type
Speed N/A No MC is installed in slot
10M 10Mbps
100M 100Mbps
1000M 1000Mbps
Duplex N/A No MC is installed in slot.
Full Full duplex
Half Half duplex
Link N/A No MC is installed in slot.
Up Link up
Down Link down
RTP * N/A Status not available
Up Remote MC TP link up
- MC in slot does not support RTP
* RTP : Remote MC TP link status monitoring is available only when
both the MC in the rack and the remote link partner support the
function through fiber link.
