English 97
Video section
Color System of External Video Input
: NTSC
External Video Input Level (mini jack)
: 1 Vp-p/ 75 Ω
External Audio Max Input Level (mini jack)
: 2 V/ 25 kΩ
Video Output Level (RCA jacks)
: 1 Vp-p/ 75 Ω
Audio Output Level (RCA jacks)
: 1.2 V/ 10 kΩ
Analog RGB input (DDX512/DDX5032 only)
: 0.7 Vp-p/ 75 Ω
Audio section
Maximum Power (Front & Rear)
: 50 W x 4
Full Bandwidth Power (Front & Rear)
(4 Ω, 14.4 V, 1 % THD)
: 22 W x 4
Preout Level (V)
: 2 V/ 10 kΩ
Preout Impedance
: 600 Ω
Speaker Impedance
: 4 – 8 Ω
Tone action
Bass : 100 Hz ± 10 dB
Middle : 1 kHz ± 10 dB
Treble : 10 kHz ± 10 dB
Navigation section
(DNX5120/DNX512EX only)
Receiver
: High-sensitivity GPS receiver
Reception Frequency
: 1575.42 MHz (C/A code)
Acquisition Times
Cold : < 38 seconds
Factory Reset : < 45 seconds
(On average for a stationary receiver with a clear
view of the sky)
Accuracy
Position : < 10 meters typical
Velocity : 0.05 m/sec. RMS
Position Method
: GPS
Antenna
: External GPS antenna
General
Operating voltage
: 14.4 V (11 – 16 V allowable)
Current Consumption
: 15 A
Dimensions (W × H × D)
: 182 Ч 112 Ч 158 mm
7-3/16 x 4-7/16 x 6-1/4 inch
Operational Temperature Range
: -10 °C – +60 °C
Storage Temperature Range
: -20 °C – +85 °C
Weight (DNX5120/DNX512EX)
: 1.90 kg (4.2 lbs)
Weight (DDX512/DDX5032)
: 1.87 kg (4.1 lbs)
Although the effective pixels for the liquid crystal panel is given as 99.99% or more, 0.01% of pixels may not light or may light
incorrectly.
Specifications subject to change without notice.
