GETTING ACQUAINTED
KCH-14 (B
ASIC
C
ONTROL
P
ANEL
)
q
q
q
q
q Power
switch
Press to switch the transceiver ON. Press and hold for approximately
1 second to switch the transceiver OFF.
w
w
w
w
w GRP
key
Press to increase the zone number. Also press to increase setting adjustments.
e
e
e
e
e GRP
key
Press to decrease the zone number. Also press to decrease setting adjustments.
r
r
r
r
r Display
Refer to page 5.
t
t
t
t
t Speaker
Internal speaker.
y
y
y
y
y TX and BUSY indicators
The TX indicator lights red while transmitting. The BUSY indicator lights
green while receiving.
u
u
u
u
u Microphone jack
Insert the microphone plug into this jack.
i
i
i
i
i VOL (Volume) control
Rotate clockwise to increase the volume level. Rotate counterclockwise to
decrease the volume level.
o
o
o
o
o CH (Channel) control
Rotate clockwise to increase the channel number. Rotate counterclockwise
to decrease the channel number. Your dealer can also enable the CH control
to be used when making setting adjustments, as an optional method for using
the GRP
and GRP
keys.
!0
!0
!0
!0
!0 PF 1 ~ PF 5 (Programmable Function) keys
Press to activate their programmable functions {page 9}.
GRP
VOL
CH
POWER
TX BUSY
q
w
r
t
e
y
u
i
o
!0
!0
