Page 21
54-0161-01
22
TracVision G6 User’s Guide
3.6
Selecting Active Satellite
After installing the pair of satellites, use the Select Satellite menu
to choose which of the installed satellites will be active. This is
also an effective way to s
ee which satellite is being tracked at any
given moment. Refer to the Quick Reference Guide on page 18
for instructions on reaching this menu.
Once you know which satellite is being tracked, switching the
active satellite can also be done at the main display, using the left
and right buttons to toggle back and forth, as shown in
Figure 3-7.
Select Satellite?
Enter
Next
Return
Select
Yes
Next
Cancel
Select
Yes
Next
cancel
Sat Name A
corresponds to the
first satellite selected
during the Install
Satellite process.
Sat Name B
corresponds to the
second satellite
selected during the
Install Satellite
process.
Figure 3-6
Select Active Satellite
Enter Main
Menu
Track Installed
Satellite A
Track Installed
Satellite B
Primary Data Displays
Magnetic Heading
###.#°
Pitch
Roll
Yaw
#.#°
#.#°
#.#°
Mag/Hdg
Rate/Sec
#.#°
#.#°
Lat:
##°
Long:
##°
Tracking
###.#°
##.#°
####
Figure 3-7
Select Active Satellite
at the Main Display
