14 | English
General features
Speaker Setting
Fine-tuning so that the System Q value is optimal
when setting the speaker type.
1 Enter Standby
Press the [SRC] button.
Select the "STANDBY" display.
2 Enter Speaker Setting mode
Press the [VOL] knob.
"SP SEL"/ "SP" is displayed.
3 Select the Speaker type
Turn the [VOL] knob.
Each time you turn the knob, the setting
alternates between the settings shown in the
table below.
Speaker type Display
OFF "OFF"/ "SP OFF"
For 5 & 4 in. speaker "5/4 inch"/ "SP 5/4"
For 6 & 6x9 in. speaker "6x9/6 inch"/ "SP 6*9/6"
For the OEM speaker "O.E.M."/ "SP OEM"
4 Exit Speaker Setting mode
Press the [VOL] knob.
Audio Setup
Setting the Sound system, such as Cross over
Network.
1 Select the source to adjust
Press the [SRC] button.
2 Enter Audio Setup mode
Press the [VOL] knob for at least 1 second.
3 Select the Audio Setup item to adjust
Press the [VOL] knob.
Each time you press the knob, the item to be
adjusted alternates between the items shown in
the table below.
4 Setup the Audio item
Turn the [VOL] knob.
Adjustment Item Display Range
Front High Pass Filter* 2 "HPF-F Fc"/
"HPF" Through/40/60/80/100/120/
150/180/220 Hz
Rear High Pass Filter* 2 "HPF-R Fc"/
"HPR" Through/40/60/80/100/120/
150/180/220 Hz
Low Pass Filter* 1,2 "LPF-SW"/
"LPF" 50/60/80/100/120/
Through Hz
Subwoofer Phase* 1,2,3 "SW Phase"/
"PHAS" Reverse (180°)/ Normal (0°)
Volume offset "Vol-Offset"/
"V-OFF" –8 — ±0
Loudness "LOUD" OFF/ON
Dual Zone System "2 ZONE"/
"2ZON" OFF/ON
• Volume offset: Sets each source’s volume as a
difference from the basic volume.
• Loudness: Compensates for low and high tones
during low volume.
• * 1 You can control this item when
(page 37) is set to "SWPRE SW". (DPX501U only)
• * 1 You can control this item when
Output> (page 15) is set to "SW ON".
• * 2 You can control this item when "2 ZONE"/ "2ZON" of
(page 14) is set to "OFF".
• * 3 You can control this item when Low Pass Filter is not
set to Through.
• Dual Zone System
Main source and sub source (Auxiliary input) output
Front channel and Rear channel separately.
- Set up the channel of sub source by
System Setting> (page 37).
- Select Main source by [SRC] button.
- Adjust the volume of Front channel by [VOL] knob.
- Adjust the volume of Rear channel by
Control> (page 12).
- The Audio Control has no effect on sub source.
• You can use the Dual Zone System with the internal
auxiliary input.
5 Exit Audio Setup mode
Press the [VOL] knob for at least 1 second.
