ii
Kingston Technology Company KNExTX/WG User’s Guide - Rev. A00
T
ABLE
O
F
C
ONTENTS
Introduction...................................................................................... 1
Model Types...................................................................... 1
Special Features ............................................................... 2
Package Contents............................................................. 2
Design Features .............................................................................. 3
Repeater Functions........................................................... 3
Receive Jabber Protection ................................................ 3
Collision-Handling ............................................................. 3
Error-Handling................................................................... 3
Automatic Port Partitioning/Reconnection ......................... 3
Hardware Installation....................................................................... 4
Front Panel........................................................................ 4
Power LED.......................................................... 4
Utilization LEDs................................................... 5
Collision LED ...................................................... 5
4 or 8 UTP Port LEDs ......................................... 5
Cascade Switch .................................................. 6
Rear Panel ........................................................................ 8
4 or 8 UTP Ports ................................................. 8
DC Power Connector .......................................... 8
Appendices...................................................................................... 9
Appendix A Pin Assignments ....................................... 10
UTP Pin Assignments ....................................... 10
