English BR VS 400 *USA 11
FAULT INDICATIONS
No or too little cleaning agent
solution on the floor
– Fill the tank with the cleaning agent
solution
– Check that the tank is firmly fitted
Unsatisfactory cleaning results
– Replace worn rotary brooms
– Check that the rotary broom or the
pads match the application on
hand.
Rotary brushes do not turn
– Remove jammed foreign bodies
– The appliance is overloaded, the
overcurrent protection switch
triggered, allow it to cool down. The
appliance is operable again after
approx. 30 s.
– Use rotary brushes suitable for job
Mains circuit breaker triggers
when the cleaner is switched on
– Ensure adequate mains fuse
protection (15 A time-lag) or use
starting current limiter
– Switch off other consumers or use
other power circuit.
Cleaner runs unevenly or vibrates
heavily
– Check the proper fit of the rotary
brooms
– Exchange the right for the left hand
rotary broom and vice versa
– Soak the rotary brooms in hot water
(approx. 15°C) for approx. 80 min.
If fault cannot be rectified, have
unit checked by After-Sales
Service.
TECHNICAL DATA
Mains fuse
(slow)
15 A
Power drive
Rated voltage
120 V (1~60Hz)
Nominal power consumption
Total
1,6 kW
Brush motor 1,55 kW
Spray pump 0,05 kW
Area performance
(theoretical)
450 m²/h
Brushes
Number
2 pieces
Diameter 95 mm
Tank
Capacity
3 Litres
option 10 Litres
Dimensions and weights
Length
530 mm
Width 450 mm
Height without protective
bracket
180 mm
Empty weight 30 kg
Working width 400 mm
Protection class I
Noise emission
Mean sound level
according to IEC 60704-1
70 dB(A)
Machine vibration
according to ISO 5349
upper limbs
< 1m/s²
