Karcher BR VS 400 - Manual (Page 10)

English BR VS 400 *USA 10
– Lay down the rotary brush on the
drive side (gearing)
– Dismantle the second rotary brush
as described
– Position the cleaner vertically
TRANSPORTATION
Note:
Movement on rollers in inside areas
and on smooth floors is not
problematic.
Take care when moving on non-
smooth floors and in outside areas.
Push the appliance onto the track
rollers
CLEANING AND CARE
– Only use a damp cloth for cleaning
the cleaner
– Wipe afterwards with a clean, dry
cloth
– Do not use chemical cleaning
agents
PROTECTION FROM FREEZING
– Store the cleaner in a room
protected from freezing
– If there is a danger of freezing
operate the upper lever until no
more liquid flows
– Emptying the tank
– Fill the tank with warm water
(max. 50°C) before taking into use
– Wait until any ice that may be in the
pump has been melted
– Only operate the upper lever now
for measuring out liquid.
RECOMMENDED CLEANING
AGENTS
* Only use cleaning agents that do
not contain solvent, hydrochloric
acid or hydrofluoric acid
Maintenance cleaning
(also on floors sensitive to alkalis)
RM 746
6.291-462
Cleaning grease
RM 69 ASF
6.291-523
Thorough cleaning (stripping) of PVC
RM 752
6.291-466
Thorough cleaning (stripping) of
linoleum
RM 754
6.291-425
Sanitary cleaner
RM 68 ASF
6.291-680
Disinfection cleaner
RM 732
6.291-382
ACCESSORIES
Rotary brush (white)
For thorough cleaning with little
soiling or for sensitive floors
1 only
4.762-249
Rotary brush(grey)
Nylon Grit, hard
For thoroughly cleaning heavily soiled
floors
1 only
4.762-252
Rotary brush (red)
high/low, for structured floors
1 only
4.762-251
Rotary brush(black)
soft, for polishing
1 only
4.762-250
Rotary broom (light blue)
soft, for carpeting
1 only
4.762-254
Rotary broom (horsehair)
natural, for polishing to a mirror finish
1 only
4.762-274
Pad
For mounting pads
1 only
4.762-228
Pads (green)
Hard
The appliance requires 2x25
20 pieces
6.369-452
Pads (bright red)
Medium
The appliance requires 2x25
20 pieces
6.369-453
Pads (yellow)
Soft
The appliance requires 2x25
20 pieces
6.369-451
Pads (white)
Very soft
The appliance requires 2x25
20 pieces
6.369-388
Tank
Contents 3 litres
For low heights
2.639-080
Tank
Contents 10 litres
For larger amounts of
cleaning agent
2.639-081
Additional weight
7 kg, for polishing
5.031-790
Additional weight
12 kg, for crystallizing
2.639-193
