E 8
Rear Panel
7. Video Output - TV
For connecting to TVs (Most TVs have this type of connections. If your TV has Component Video or S-
Video, you will get a better picture by using them instead).
8. S - Video Output
For connecting the S-VIDEO IN jack on the TV using an optional S-Video cable. This type of connection will
provide superior picture quality. However, your TV must be equipped with an S-Video input socket.
9. Digital Coaxial Input
For connecting external equipment that has a digital coaxial output jack.
10. Digital Coaxial Output
For connecting an external equipment that has digital audio input jack, such as a CDR recorder.
11. Digital Optical Input
For connecting an external equipment that has a digital optical output jack.
12. Subwoofer Speaker
For connecting the passive subwoofer, with colored wire to “+” terminal and black wire to “-” terminal.
13. Surround Speaker (Rear Speakers)
For connecting the left surround speaker to “SL” terminals and right surround speaker to “SR” terminals.
Connect the colored wire to “+” and black wire to “-” .
14. Front Speaker
For connecting the left front speaker to “L” terminals, right front speaker to “R” terminals and center
speaker to “C” terminals. Connect the colored wire to “+” and black wire to “-”.
15. Active Subwoofer Out
For connecting an external powered subwoofer.
16. Power Cord
