Konica Minolta Non-Contact 3D Digitizer Range7 - Manual (Page 23)

21
n Specifications
MODEL NAME KONICA MINOLTA RANGE7
Measuring Method Triangulation by light sectioning method
Light-Source Semiconductor laser λ = 660 nm
Laser Classification Class 2 (IEC60825-1 edition2)
Sensor
Name CMOS Photo diode
Pixel 1.31 Mega Pixel (1280 x 1024)
Measuring Distance (mm) 450 to 800 (Distance from Light-Receiving Lens *1)
Light Receiving Lens (Replaceable) TELE / WIDE
Measuring
Range
(mm)
MultiFocus
mode
Disabled
Lens TELE TELE WIDE WIDE
Distance 450 800 450 800
X-Y size 79 Ч 99 141 Ч 176 150 Ч 188 267 Ч 334
Z 54 97 109 194
Meas.pitch of X-Y 0.08 0.14 0.16 0.28
MultiFocus
mode
Enabled
Lens TELE TELE WIDE WIDE
Distance 462 781 475 766
X-Y size 81 Ч 102 138 Ч 172 159 Ч 199 256 Ч 320
Z 54 97 109 194
Meas.pitch of X-Y 0.08 0.13 0.08 0.25
Accuracy (Interglobuler distance)*2 ±40 μm
Precision (Z, σ)*3 4 μm
Auto Focus available
Auto Exposure available
Scanning Time about 2 sec. per scan
Preview Function available (about 0.4 sec. per scan)
Environment Brightness 500 lx or less
File Format *4 INPUT/OUTPUT: .rgv, .rvm, .rmk (Original format), OUT only: .stl
Output Interface USB 2.0 HighSpeed
Power Supply
AC adapter
100-240Vac (50-60 Hz), 1.4A
External Dimensions (mm)
295 (W) x 190 (H) x 200 (D)
* exclude the protruding portion of the lens and handle
Weight (kg) about 6.7
Operating Condition 10 to 40ºC (relative humidity 65% or less, with no condensation)
Storage Condition
-10 to 50ºC (relative humidity 85% or less [at 35ºC] , with no
condensation)
Remarks (Controlled Method) Controlled via dedicated PC software "RANGE VIEWER"
*1 Due to the difference of origins on the measurement reference surface and measurement data, the Z axis coordinate has an offset of about 120 mm for the measuring
distance.
*2 When the interglobuler distance for the ball bars (2 globes) specified in VDI/VDE2634-2 is measured under the following conditions defined by KONICA
MINOLTA OPTICS:
Our conditions: Temperature 20±1ºC / Using the TELE lens / Distance 450 mm / Warming up 20 mins. / Using the KONICA MINOLTA OPTICS processing
software / With Calibration / Object to be measured: Standard KONICA MINOLTA OPTICS (2 globes) instrument / Position of object to be
measured: KONICA MINOLTA OPTICS standard position (10 locations within the measurement space) / Does not cover the uncertainty over the
pricing of the standard instrument.
*3 Measuring conditions: Temperature 20±1ºC / Using the TELE lens / Distance 450 mm / Warming up 20 mins. / Using the KONICA MINOLTA OPTICS processing
software / Object to be measured: KONICA MINOLTA OPTICS reference plain chart / 1σ
*4 Using the KONICA MINOLTA OPTICS “RANGE VIEWER” processing software
• The RANGE7 includes the eT-Kernel/Compact from sSOL Co., Ltd.
