Parts List
25
Ref #
Part #
Description
Qty
Ref #
Part #
Description
Qty
1
423-00014 TOP RAIL, HEALTHTRAINER
1
63
402-00067 PHILIP SCREW ST4.2*16
41
2
423-00021 LEFT UPRIGHT
1
64
402-00031 PHILIP SCREW ST4.2*13
6
3
423-00022 RIGHT UPRIGHT
1
65
402-00019 PHILIP SCREW ST4.2*13
4
4
423-00023 DECK FRAME
1
66
402-00016 PHILIP SCREW ST4.2*13
26
5
423-00024 BASE FRAME
1
67
402-00035 SCREW ST2.9*6.5
19
6
423-00025 ELEVATION FRAME
1
68
402-00035 SCREW ST2.9*6.5
4
7
423-00026 ELEVATION SUPPORT
1
69
402-00107 CHAMFER BOLT ST4.8*25
4
8
419-00013 LINKAGE PLATE
2
70
402-00023 NYLON LOCK NUT M10
6
9
404-00002 POLY V-BELT 200J8(508J8)
1
71
402-00021 NYLON LOCK NUT M8
3
10
404-00011 WALKBELT, 20*56 NW-TIRE ORTHO, HT95T/550
1
72
402-00108 JAM NUT M8
4
11
403-00007 WALKING BOARD, 20*56 NW
1
73
402-00026 WASHER 9*16*1.6 (mm)
3
12
409-00007 FRONT ROLLER
1
74
402-00161 LOCK WASHER, INTERNAL TEETH
8
13
409-00008 REAR ROLLER
1
75
402-00109 WASHER 11*23*2
4
14
406-00137 MOTOR COVER, HT-CLASSIC/PRO/ELITE
1
76
402-00110 SCREW 8-32-3/8
1
15
406-00138 FENDER LEFT, HT-CLASSIC/PRO/ELITE
1
77
402-00111 SCREW 8-32-5/8
1
16
406-00139 FENDER RIGHT, HT-CLASSIC/ELITE/PRO
1
78
402-00104 SHOULDER ALLEN BOLT M8*80
2
17
406-00140 HANDLE COVER, LEFT OUSTSIDE, BLACK
1
79
402-00113 GEAR WASHER D5
1
18
406-00141 HANDLE COVER, LEFT INSIDE, BLACK
1
80
402-00080 GEAR WASHER D2.5
2
19
406-00142 HANDLE COVER, RIGHT OUTSIDE, BLACK
1
81
402-00046 CLIP NUT
4
20
406-00143 HANDLE COVER, RIGHT INSIDE, PRO
1
82
402-00048 PAN SPRING WASHER 10*19*0.25
4
21
419-00021 END CAP LEFT SILVER, 45/5500T
1
83
402-00114 SHOULDER ALLEN BOLT M8*60
1
22
419-00020 END CAP, RIGHT SILVER, 45/5500T
1
84
402-00137 PHILIP SCREW ST3.5 * 19
8
23
406-00072 FRONT WHEEL
2
85
402-00116 CHAMFER BOLT ST4.8*16
3
24
406-00044 REAR WHEEL
4
86
402-00034 ALLEN WRENCH 110*75*6
1
25
419-00012 REAR WHEEL SHAFT
2
87
413-00012 ENCODER HARNESS
1
26
406-00073 ELEVATION WHEEL
4
88a
413-00013 CONSOLE HARNESS, 3PC
1
27
406-00074 TOP HANDLE
2
88b
413-00025 CONSOLE HARNESS B
1
28
406-00075 BOTTOM HANDLE
2
88c
413-00026 CONSOLE HARNESS C
1
29
410-00020 PULSE RECEPTACLE PLATE - TOP
2
89a
413-00023 SPD AND INCL HARNESS B
2
30
410-00021 PULSE RECEPTACLE PLATE - BOTTOM
2
89b
413-00021 SPD AND INCL HARNESS A
2
31
406-00076 DOME END CAP 35mm
2
90a
413-00022 EKG HARNESS A
1
32
405-00018 EXTRUSION, 35*84*1275 (BRIGHT SURFACE)
2
90b
413-00024 EKG HARNESS B
1
33
406-00092 BOTTOM SHEET, HT75/85/95T, 4500/5500
1
91
413-00017 JUMPER WIRE
1
34
406-00148 DECK BUMPER, HT-CLASSIC/PRO/ELITE (BLUE)
8
92
413-00004 POWER CORD
1
35
410-00036 LATCH SET
1
93
408-00015 CIRCUIT BREAKER IN-011
1
36
419-00014 STOPPER BRACKET
1
94
408-00024 ENCODER
1
37
402-00103 METAL BUSHING
2
95
408-00022 FUSE, 08-0156, 12AMP
1
38
419-00015 BOLT SHAFT A
2
96
408-00023 FUSE, 08-0157, 15AMP
1
39
419-00016 BOLT SHAFT B
2
97
408-00005 FERRITE CORE
1
40
406-00079 BASE BUMPER, 28*25*13
6
98
407-00006 SPEED INCLINE PCB, 07-0079
2
41
419-00019 BELT GUIDE BRACKET, HT95T/4500T/5500T
2
99
413-00016 REED SWITCH
1
42
410-00041 SOFT DROP SHOCK, 600N (5/16")
1
100
413-00031 TEL-LINE, HT95T/HT65T.1/75T.1, 4500/5500
1
43
406-00045 ADJUST SUPPORT
2
102
407-00100 CONSOLE PCB, HT95T, IN-020
1
44
406-00080 CORD SPACER
4
103
406-00089 PCB DOME BUTTON
1
45
406-00057 POWER CORD SPACER
1
104
407-00018 EKG MODULE, 07-0092
1
46
419-00009 REED SWITCH PLATE
1
105
402-00090 KILL SWITCH MAGNET
1
47
406-00041 PLUG CALIBRATION HOLE
2
106
412-00008 MOTOR,12-0057
1
48
406-00144 CONSOLE BOX TOP (C), BLACK
1
107
406-00090 FAN FOR MOTOR
1
49
406-00145 CONSOLE BOX BOTTOM (C), BLACK
1
109
407-00007 MOTOR CONTROLLER, 08-0158
1
50
406-00093 INSERT
1
110
412-00007 ACTUATOR, IN-064
1
51
406-00146 BOTTLE HOLDER LEFT, BLACK
1
111
414-00009 SPEED DECAL, 14-0520
1
52
406-00147 BOTTLE HOLDER RIGHT, BLACK
1
112
414-00008 INCLINE DECAL, 14-0521
1
53
402-00135 WASHER, DISHING
10
113
414-00035 OVERLAY, HT95T, IN-077
1
54
406-00109 BUMPER
2
114
414-00037 DECAL HEALTH TRAINER, CONSOLE, IN-054
1
55
402-00008 HEX BOLT M10*60
1
115
414-00005 HEALTH TRAINER MOTOR COVER DECAL,14-0464
1
56
402-00009 HEX BOLT M10*45
1
116
414-00038 DECAL, MOTOR COVER GRAPHIC, IN-099
1
57
402-00010 ALLEN BOLT M8*50
2
117
414-00002 SAFETY KEY DECAL, IN-008
1
58
402-00011 ALLEN BOLT M8*15
8
118
414-00036 SERIAL LABEL, INRAY
1
59
402-00105 ALLEN BOLT M10*15
4
119
414-00039 LABEL, HP FOR HT95T/5500T
1
60
402-00106 CHAMFER BOLT M6*25
8
121
415-00059 OWNERS MANUAL HT-ELITE
1
61
402-00018 PHILIP SCREW M6*12
11
#
408-00027 TRANSFORMER, HT95T/4500T/5500T
1
62
402-00136 PHILIP SCREW M4*12
12
HT-ELITE Parts List Rev A
