CONNECTIONS
Speaker Components
SubWooFer StanD baSe
Front
SCREW (Large): 8EA SCREW (Small): 12EA
CRADLE STAND/
WALL MOUNT
CENTER CENTER
HoLe CoVer
(L) (r)
StanD
Center
rear
(L) (r)
Installing the Cradle Stand (Center speaker)
1. Insert the stand so that it fi ts into the hole as described in the fi gure.
2. Turn the stand clockwise to lock it.
(Turning it counter-clockwise will loosen from the hole.)
3. This is the completion of the stand installation.
1
3
