CONNECTING CAbLE ASSEMbLY

Determine whether you’ll be using the battery clamps (750 watt out-

put maximum) or accessory plug (120 watt output maximum).
Make sure that there is no device plugged into inverter before making con-

4.1

nection.
Unscrew the positive (red) and negative (black) plastic connector knobs

4.2

from the studs on the back of the inverter.
Slip the red (positive) ring terminal of the 12V accessory plug over the red

4.3

(positive) stud. Screw on the connector knob and tighten securely. Repeat

the same process for the black ring terminal.
Accessory Plug:

4.4

Push the 12V accessory plug firmly into a 12V acces-

sory outlet.
battery Clamps: Connect the red (positive) battery clamp to the posi-

tive (+) battery terminal. Connect the black (negative) battery clamp to

the negative (-) battery terminal, taking care to shield eyes, clothing and

hands from battery acid.

USING INVERTER

Determine the wattage of device being used. The Power inverter 750

must be used with devices drawing 750 watts or less when being

used with the battery Clamps and 120 watts or less when using the

Accessory Plug.
Plug the device to be operated into either the AC outlet of the inverter or

5.1

USB connector. NOTE: If using more than one device, the total combined

wattage of both devices must not exceed 750 watts.
Press and hold

5.2

the ON/OFF button to turn the inverter ON. The VOLT-

AGE IN indicator will glow and the digital display will show the DC input

voltage.
Turn the device ON. To show AC VOLTAGE OUT, press the ON/OFF

5.3

button once. Press the ON/OFF button once again to show total wattage

used by the device (POWER OUT). NOTE: If there is a short circuit or

power surge in the device, SC will display and an alarm will sound. Press

the ON/OFF button to turn off the alarm. If the SC displays after several

attempts, there is a short circuit or the device requires more surge power

than the inverter is capable of providing.
TO DISCONNECT THE INVERTER:

5.4

Turn device OFF

•

Press and hold

•

the ON/OFF button to turn the inverter OFF

Unplug the device from inverter

•

If using the

•

Accessory Plug, unplug inverter from 12V DC accessory

outlet. If using the

battery Clamps, unclamp inverter from 12V battery.
