26

P/N 211789

02/04

Assemble lower elevator tubes (35) and rim to brackets (49) using
bolts (40), plastic spacers (42), metal spacer (44) and nuts (37) as
shown.

15.

49

42

35

37

40

42

Refer To Instructions Included

With Rim Hardware For Rim

Assembly.

Use the 5/16-18 x 1" hex-flange

bolts for installing rim to the

acrylic backboard.

NOTE:

44
