Stellar Industries TELESCOPIC CRANE EC2000 - Manual (Page 9)

5 Installation 5
3,4,5
ROTATION
M OTOR
BLACK
RED
CUTW INCH CABLETO
6.5',W ITH 6"OF W IRE
INSIDEOFBOX
2
GROUND
POW ER
ROTATION
CW
RELAY
FRONT
VIEW
POW ER
ROTATION
AUX
BREAKER
POW ER
12V
BAT
GD
RT
LT
SA
TM
BLK
GRN
ROTATION
CCW
RELAY
W INCH DOW N
UP
Rotation
ITEM PART NO. DESCRIPTION QTY
01 28834 WIRE HARNESS 1
02 22932 HANDLE ASM 2 FCTN EC2K POWER 1
03 9751 CONNECT 2 PIN SHROUD PACKARD 1
04 11359 CABLE SEAL 14-16 PACKARD 39001 2
05 13564 CONTACT M TERM SHROUD 12 32038 2
Rotation
Motor
Black
Red
3,4,5
Ground
Power
Breaker
Power
12V
Power
Rotation
Blac
k
Green
Front
View
Bat
Aux
GD
TM LT
SA RT
Cut winch cable to
6.5’ with 6” of wire
inside of box.
Rotation
CCW
Relay
Rotation
CW
Relay
PN 22930
Control Kit Power Rotation - PN 22930
