Product overview
6
Product overview
Overview of the SK 300 G3 bodypack
transmitter
³
Microphone/instrument input (
MIC
/
LINE
),
3.5 mm jack socket, lockable
· MUTE
switch
»
Socket for connection of RMS 1 external mute switch,
2.5 mm jack socket
¿
Antenna
´
Operation and battery status indicator, red LED
(lit =
ON
/flashing =
LOW BATTERY
)
²
Audio overmodulation indicator, yellow LED
(lit =
AF PEAK
)
¶
Charging contacts
º SET
button
¾ ̆
/
̄
rocker button (
UP
/
DOWN
)
µ
Battery compartment
¸
Battery compartment cover
¹
Battery compartment catches
Ƹ
Infra-red interface
ƹ ON
/
OFF
button
with ESC function (cancel)
ƺ
Display panel, backlit in orange
³
¿
´
²
º
¶
ƹ
¶
ƺ
µ
¸
¾
¹
¹
· »
Ƹ
