12
ready for selection (its corresponding front panel indicator is green),
or the color is white as it has no power. OSD menu updates the color
when it is activated. Use the and arrow keys to
highlight a computer and the key to select it. Or, you may
press to exit OSD and remove the OSD menu from the
display; the status window returns to the display and indicates the
currently selected computer or operating status.
A triangle mark ( 4) to the right of a name indicates the port is
cascaded to a Slave; the number at the left of the triangle mark
shows the number of ports the Slave has, i.e. 8
4for SV831D.
key brings you one level down and another screen pops
up listing the names of the computers on that Slave. The name of
the Slave will be shown at the upper right corner of the OSD menu.
It is useful to group computers and still be able to see the
group name.
An eye mark ( N ) to the right of a name indicating the computer is
selected to be monitored in Scan mode. In OSD, this mark can be
switched on or off by function key .
Press key to exit OSD and to return to the selected
computer; the computer name is also shown on the screen.
=
Function key : To edit name entry of a computer or a Slave.
First, use the and arrow keys to highlight a channel
then press followed by name entry. Valid characters are ‘A’~’Z’,
‘0’~’9’ and the dash character. Lowercase letters are converted to
uppercase ones. Press to delete a letter one at a
time. Non-volatile memory stores all name entries until you change,
even if the unit is powered down.
=
Function key : To switch the eye mark ( N) of a computer on
or off. First, use the and arrow keys to highlight it,
then press to switch its eye mark on or off. If Scan Type is
'Ready PC +
N ', only the power-on and eye mark selected
computers will be displayed sequentially in Scan mode.
